Pliteq GenieClip RST is a sound control clip

GenieClip® RST

An innovative, affordable and reliable sound solution GenieClip RST is engineered for superior acoustic performance in reducing the transmission of airborne and impact sound through wall and floor/ceiling assemblies.

GenieClip RST is a unibody molded rubber and galvanized steel part used to attach plasterboard to either wall or floor/ceiling assemblies. Made from recycled components, and engineered to allow reduction in assembly weight.

Patents: US 7,895,803, US 9,121,469, CA 2,552,516, AU 2,007,276,677, CN 101,631,919, EPO Patent Pending

Significantly improve low frequency sound control performance
Substantially improve impact noise and help stop sound travelling through walls and floor/ceiling construction
Allow for thinner and even no resilient mat used in certain floor/ceiling assemblies
Substantially reduce costs and associated problems in wood truss floor/ceiling construction and still meet code for fire and sound control—great for multi-family construction

EASY TO INSTALL

GenieClip RST is easy and fast to install using Pliteq’s proprietary steel furring channel and is extremely stable when held in place with a single fastener. There is nothing to adjust or site fit. The furring channel is simply snapped into the GenieClip RST and the plasterboard can be immediately installed.

Only one screw required to attach metal clip to wood or metal wall studs or floor joists.

Engage the furring channel into either claw, then squeeze channel to engage the claw.

GenieClip RST installed into wall with resilient channel being inserted into GenieClip RST
GenieClip RST being drilled into the wall

Product Video

An innovative, affordable, and reliable tool for reducing sound transmission through walls and ceilings. See how you can improve noise control and reduce material costs on your upcoming projects.

Application for Floor-Ceiling Assemblies

Benefits
  • Excellent low frequency performance allows for design options in wood construction with or without the use of a screed.
  • Concrete slab results with significant broadband sound reduction
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Ln,w
Open Web Wood Trusses
Wood Truss with GenieClip RST and Gypsum Concrete
E5958.12
Vinyl Plank Flooring
63
55
Wood Truss with GenieClip RST and NO Gypsum Concrete
E5958.17
Vinyl Plank Flooring
59
59
Engineered Joists
TJI Floor Joist with GenieClip RST and Gypsum Concrete
F4832.07
Wood Flooring
61
47
F4832.05
Porcelain Tile
60
48
F4832.09
Vinyl Plank
63
46
TJI Floor Joist with GenieClip RST and NO Gypsum Concrete
F5500.04
Wood Flooring
61
50
F5500.02
Porcelain Tile
62
54
F5500.03
Vinyl Plank
60
49
Solid Wood 2 x 10 Joist
Solid Joist with No Gypsum Concrete
5013136 | 7013208
Ceramic Tile
57
58
5013143 | 7013216
Vinyl Plank
54
59
Solid Joist Retrofit Ceiling
5013119
Ceramic Tile
58
54
Hollow Core Plank
8” Hollow Core Plank
F0223.08
Porcelain Tile
60
49
F0223.05
Vinyl Plank
62
48
F0223.06
Bare
62
55
Steel Floor Systems
Steel Deck and Joist System
F2761.04
Bare
59
58
F2761.05
Wood Flooring
58
48
Composite Floor Systems
16” Insulated Concrete Form
F3052.12
Wood Flooring
62
45
4” Normal Weight Composite Deck
F5689.06
Wood Flooring
56
56
Timber Floors
Cross Laminated Timber
F2761.08
Wood Flooring
53
59
F2761.09
Porcelain Tile
55
59
Wood Beam and Plank
5015105 | 7015157
Bare
58
50

Application for Wall Assemblies

Benefits
  • Performance similar to a double stud wall, but with a substantial reduction in building materials
  • Decrease wall thickness and increase valuable floor space
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Metal Stud
GenieClip RST with 2 layers
TL07-620
55
GenieClip RST with 3 layers
TL07-617
59
GenieClip RST with 4 layers
TL07-618
63
Wood Stud
GenieClip RST with 2 layers
TL07-673
55
GenieClip RST with 3 layers
TL07-672
60
GenieClip RST with 4 layers
TL07-670
63
Engineered Partitions
Save Material with GenieClip RST
TL07-620
55
OLD WAY to save material with 4 layers
TL07-616
48
Save Space with GenieClip RST
TL07-672
60
OLD WAY with Staggered or Double Studs (metal or wood)
TL11-121
47
TL11-120
61

Application for Retrofit Assemblies

Benefits
  • Improves Ln,w performance by 8-12 dB in floor ceiling retrofit assemblies
  • Increase Rw by 12-18 dB in wall retrofit assemblies
  • Retrofit directly to existing ceiling or wall
  • Greater Rw performance than other popular retrofit solutions
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Assembly
Floor/Ceiling
Wall

GenieClip RST Specifications

GenieClip RST 3-Part Guide Spec

Download

GenieClip RST Submittal Drawing

Download

GenieClip RST Model CAD Drawing (PDF)

Download

GenieClip RST Model CAD Drawing (DWG)

Download

GenieClip RST Installations

GenieClip RST Installation Instructions

Download

GenieClip RST Technical Reports

Resilient Channels: Guaranteed to Fail

Download
Floor/Ceiling Application

Application for Floor-Ceiling Assemblies

Benefits
  • Excellent low frequency performance allows for design options in wood construction with or without the use of a screed.
  • Concrete slab results with significant broadband sound reduction
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Ln,w
Open Web Wood Trusses
Wood Truss with GenieClip RST and Gypsum Concrete
E5958.12
Vinyl Plank Flooring
63
55
Wood Truss with GenieClip RST and NO Gypsum Concrete
E5958.17
Vinyl Plank Flooring
59
59
Engineered Joists
TJI Floor Joist with GenieClip RST and Gypsum Concrete
F4832.07
Wood Flooring
61
47
F4832.05
Porcelain Tile
60
48
F4832.09
Vinyl Plank
63
46
TJI Floor Joist with GenieClip RST and NO Gypsum Concrete
F5500.04
Wood Flooring
61
50
F5500.02
Porcelain Tile
62
54
F5500.03
Vinyl Plank
60
49
Solid Wood 2 x 10 Joist
Solid Joist with No Gypsum Concrete
5013136 | 7013208
Ceramic Tile
57
58
5013143 | 7013216
Vinyl Plank
54
59
Solid Joist Retrofit Ceiling
5013119
Ceramic Tile
58
54
Hollow Core Plank
8” Hollow Core Plank
F0223.08
Porcelain Tile
60
49
F0223.05
Vinyl Plank
62
48
F0223.06
Bare
62
55
Steel Floor Systems
Steel Deck and Joist System
F2761.04
Bare
59
58
F2761.05
Wood Flooring
58
48
Composite Floor Systems
16” Insulated Concrete Form
F3052.12
Wood Flooring
62
45
4” Normal Weight Composite Deck
F5689.06
Wood Flooring
56
56
Timber Floors
Cross Laminated Timber
F2761.08
Wood Flooring
53
59
F2761.09
Porcelain Tile
55
59
Wood Beam and Plank
5015105 | 7015157
Bare
58
50
Wall Application

Application for Wall Assemblies

Benefits
  • Performance similar to a double stud wall, but with a substantial reduction in building materials
  • Decrease wall thickness and increase valuable floor space
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Metal Stud
GenieClip RST with 2 layers
TL07-620
55
GenieClip RST with 3 layers
TL07-617
59
GenieClip RST with 4 layers
TL07-618
63
Wood Stud
GenieClip RST with 2 layers
TL07-673
55
GenieClip RST with 3 layers
TL07-672
60
GenieClip RST with 4 layers
TL07-670
63
Engineered Partitions
Save Material with GenieClip RST
TL07-620
55
OLD WAY to save material with 4 layers
TL07-616
48
Save Space with GenieClip RST
TL07-672
60
OLD WAY with Staggered or Double Studs (metal or wood)
TL11-121
47
TL11-120
61
Retrofit Application

Application for Retrofit Assemblies

Benefits
  • Improves Ln,w performance by 8-12 dB in floor ceiling retrofit assemblies
  • Increase Rw by 12-18 dB in wall retrofit assemblies
  • Retrofit directly to existing ceiling or wall
  • Greater Rw performance than other popular retrofit solutions
Assemblies
Click on one of the assemblies to view details**
Assembly
Test Number
Rw
Assembly
Floor/Ceiling
Wall
Specifications

GenieClip RST Specifications

GenieClip RST 3-Part Guide Spec

Download

GenieClip RST Submittal Drawing

Download

GenieClip RST Model CAD Drawing (PDF)

Download

GenieClip RST Model CAD Drawing (DWG)

Download
Installations

GenieClip RST Installations

GenieClip RST Installation Instructions

Download
Technical Reports

GenieClip RST Technical Reports

Resilient Channels: Guaranteed to Fail

Download
